10.1" to 27" Industrial Panel PC with J1900, i5 4th/7th/10th/12th-GEN CPU Options | Wall-Hanging / Desktop Stand Install
In today’s fast-growing industrial automation landscape, choosing a reliable and flexible industrial panel PC is essential for improving productivity, stability, and operational intelligence. The 10.1" to 27" Industrial Panel PC with J1900, i5 4th/7th/10th/12th-GEN CPU options is designed to deliver exceptional performance, flexible installation, and long-term durability for harsh working environments. Whether used in manufacturing, smart factories, equipment control, or kiosk applications, this panel PC provides a powerful and cost-effective solution.
Product Model Fast Guide
| Product Models | LCD Displays | Resolution | Aspect Ratio | Brightness | Dimension (L*W*D) | Get A Quote Now! |
| JWS101-W23 | 10.1"
| 800*1280 | 10:16 | 300cd/㎡ | 260.45*162.95*52mm | Inquiry |
| JWS104-W23 | 10.4" | 1024*768 | 4:3 | 400cd/㎡ | 266.3*206.3*57.5mm | Inquiry |
| JWS116-W23 | 11.6" | 1920*1080 | 16:9 | 250~300cd/㎡ | 305*193*52.5mm | Inquiry |
| JWS120-W23 | 12" | 1024*768 | 4:3 | 500cd/㎡ | 295.4*234.4*54.5mm | Inquiry |
| JWS133-W23 | 13.3" | 1920*1080 | 16:9 | 400cd/㎡ | 340.62*212.17*56.5mm | Inquiry |
| JWS150-W23 | 15" | 1024*768
| 4:3 | 350cd/㎡ | 358.4*281.4*58.5mm | Inquiry |
| JWS156-W23 | 15.6" | 1920*1080 | 16:9 | 300cd/㎡ | 388.55*240.98*52.5mm | Inquiry |
| JWS170-W23 | 17" | 1280*1024 | 5:4 | 250~300cd/㎡ | 388.4*325.4*60.5mm | Inquiry |
| JWS173-W23 | 17.3" | 1920*1080 | 16:9 | 400cd/㎡ | 433.4*268.4*58.5mm | Inquiry |
JWS185-W23 | 18.5" | 1920*1080
| 16:9 | 300cd/㎡ | 461.4*283.4*61.5mm | Inquiry |
| JWS190-W23 | 19" | 1280*1024 | 5:4 | 250~300cd/㎡ | 428.4*353.4*61.5mm | Inquiry |
| JWS215-W23 | 21.5" | 1920*1080 | 16:9 | 250~300cd/㎡ | 526.4*321.4*60.5mm | Inquiry
|
| JWS238-W23 | 23.8" | 1920*1080 | 16:9 | 250~300cd/㎡ | 527.4*347.9*61.5mm | Inquiry |
| JWS270-W23 | 27" | 1920*1080 | 16:9 | 250~300cd/㎡ | 661.5*398.5*61.5mm | Inquiry |
Note: High-brightness screen optional.
Wide Display Options: 10.1" to 27" for Diverse Applications
This industrial panel PC is available in a wide range of display sizes from 10.1 inches to 27 inches, making it suitable for compact equipment, large production terminals, and information display systems. Users can select the ideal size based on project needs, such as Production line HMI terminals, Factory automation control panels, Industrial machinery interfaces, Kiosk, and self-service machines, Information display and monitoring platforms. The full-range panel size availability ensures seamless integration across various industrial scenarios.
Flexible CPU Options: From J1900 to 12th-Gen Intel® i5
To meet different performance requirements, this industrial panel PC supports a broad range of CPUs, including:
Intel® Celeron® J1900 – Cost-effective, stable, suitable for basic automation tasks
Intel® Core™ i5 4th Gen – Reliable performance for standard industrial applications
Intel® Core™ i5 7th Gen – Enhanced processing and graphics capability
Intel® Core™ i5 10th Gen – Great for multi-tasking and real-time control systems
Intel® Core™ i5 12th Gen – High-speed, powerful CPU for advanced automation and AI edge computing
These multiple processor options ensure that integrators and end-users can select a configuration that matches their required computing power and budget.
Industrial-Grade Durability for Harsh Environments
Designed for continuous 24/7 operation, the industrial-grade panel PC offers robust protection and high reliability. Key industrial-grade features include Fanless Cooling System – Reduces dust accumulation and mechanical failure. IP65 Front Waterproof Panel – Protects against water splash, dust, and oil vapor. Wide Operating Temperature Options – Suitable for cold rooms, hot factories, and unstable environments. And Aluminum Alloy Housing – Improves heat dissipation and structural strength.
These features ensure stable operation in industrial automation, production lines, and equipment integration.
Flexible Installation: Wall-Mount, VESA, Desktop Stand, or Ceiling-Mounted
To support various workspace layouts, the panel PC offers multiple installation methods:
✔ Wall-Hanging Installation
Ideal for factory sites, smart buildings, and machine interfaces where space optimization is crucial.
✔ VESA mount
Ideal for easy integration with automation machines or control cabinets.
✔ Desktop Stand Installation
Perfect for offices, reception areas, POS systems, and operator stations requiring mobility and easy placement.
This flexible installation design enhances usability across multiple industries.
✔ Ceiling-Mounted
Ideal for a smart workshop in a digital factory.
