17.3" Industrial Flat Panel Touch Screen Monitor Outdoor Use Weather-proof


● Display size: 17.3-inch.

● High-level anti-static.

● High-quality industrial LCD panel.

● Working temperature:-10 ~ +60°C.

● Industrial grade display chip.

● 10mm bezel Aluminum touch monitor.

● Support 7*24 hours long-time running.

● IP65 rated dust-proof and waterproof.

Appearance of the color
Black
Silver
share:
  • Description
  • Parameter
  • Case
  • 17.3" Industrial Touch Screen Monitor


    It's important to protect hardware when using industrial LCD monitors outdoors or in harsh industrial environments, while this point is not easy for commercial-grade monitors. Industrial monitors are compliant with IP65-rating protection, which means the equipment is being protected from hazardous elements such as dirt or water. Jawest provides this type of LCD monitors in fields of industrial automation, IIOT, IoT, AI, remote access, security system, and other embedded solutions. These monitors are integrated with extremely durable and high brightness displays, ranging from 300nits to 1500nits. And offers more screen visibility even when used under direct sunlight or a high lighting environment. Our product features extended operating temperature for the device to withstand extreme conditions such as super hot or super cold. Besides, the high contrast ratio and outstanding vivid color deliver superior image quality.


    Jawest Industrial Monitor Features


    ● IP65 / NEMA4 rated dust and water resistance

    ● 300~1,500NIT sunlight readable with long-service life LED backlight

    ● Automatic backlight adjustment through a built-in ambient light sensor

    ● Support anti-reflective and anti-fingerprint coating

    ● Plug-and-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS)

    ● Multi-monitor touchscreen support

    ● HDMI, VGA, Video, DVI, Audio input, and offer Built-In waterproof speaker

    ● 1920x1080 native resolution, 16:9 aspect ratio

    ● Solid capacitors for improved durability

    ● Industrial motherboard with explosion-proof, flameproof, moisture-proof, anti-surge.

    ● Shock resistance standard reached GB2423, well-protected during transportation.

    ● Power supply management: TI chipset, wide range 12-24V input

    ● The industrial monitor supporting a multi-functional module customization service.


    17.3" All-Weather Touchscreen Monitors


  • 17.3" Industrial Touch Screen Monitor Datasheet
    Size17.3 inch
    Display
    Panel TypeIndustrial LCD panel A, A+ grade
    Aspect Ratio16:9
    Resolution1920*1080
    Contrast1000:1
    Luminance250nit-1500nit
    Response time5ms
    Active Area (mm)341.5*274
    Display colors16.7M(8-bit)
    View angle75/75/75/75
    Touch ScreenCapacitive touch screen (resisitve and Infrared touch for optional)
    InterfaceHDMI+DVI+VGA+USB/DVI+VGA+USB optional
    Power InputAC 110-240V, 50/60Hz
    Power Consumption≤30W
    Power Standby≤1.5W
    Plug&PlayDDC1/2B
    Working LifeMore than 50,000 hours
    Operation Temperature-10°C-60°C
    Storage Temperature-10°C-60°C
    Operation Humidity10%--80%
    Storage Humidity10%-90%
    Metal ShellAluminum alloy enclosure
    ColorSilver, black color optional
    Bezel thickness10mm bezel (3mm bezel for optional)
    IP ratingIP65 protection for front Panel
    InstallationVESA, Embedded, Wall Mount, Desktop optional
    CertificatesCE,CCC,ISO,FCC,ROHS
    PackageEPE+Carton  (wooden crate for mass order)
