10.1" Embedded LCD Displays VGA WIFI HDMI Port


Model: JWS101-M2

● Display size: 10.1 inch

● High-level anti-static

● High-quality industrial LCD panel

● Working temperature: -10 to +60°C

● Industrial-grade motherboard

● Ultra-thin bezel Aluminum touch panel monitor

● 7*24hours running in harsh conditions

● IP65 rated dust-proof and water-proof for front panel

Appearance of the color
Black
Silver
share:
  • Description
  • Parameter
  • Case
  • 10.1" Embedded LCD Displays with VGA WIFI HDMI Port


    Model: JWS101-M2


    Jawest 10.1″ industrial LCD display is designed to provide superior high-resolution image quality and is equipped with strong anti-oxidation aluminum alloy material rugged full-enclosure and industrial grade motherboard, which ensures long-term reliable and stable operation under harsh industrial and factory environments. They are fitted with universal usage of DC or AC power input making these touchscreen monitors highly versatile. Backed by industrial certifications (including 3rd-party environmental testing) and an industry-leading 3-year warranty.



    Jawest Industrial Monitor Features


    1. High contrast color TFT-LCD industrial monitor offers high resolution 1280 x 800.

    2. Multi-installation methods: VESA arm, desktop, panel, wall-mounted, and open frame monitor.

    3. Provide a universal Power adapter.

    4. Support Plug-and-Play compatibility.

    5. OSD control for picture quality adjustment on the back of the panel.

    6. Durable and rugged monitor with an aluminum alloy frame.

    7. Custom design by request.


  • Industrial touch monitor datasheet
    Size10.1 inch
    Display
    Panel Type Industrial LCD panel A+ grade
    Aspect Ratio16 : 10
    Resolution1280 * 800
    Contrast800:1
    Luminance300nit-1500nit
    Response time5ms
    Active Area (mm)135.36*216.576
    Display colors16.7M(8-bit)
    View angle85/85/85/85
    Touch Screen5-wire resistive touch screen / 10-point capacitive touch screen / Non-touch
    InterfaceHDMI+DVI+VGA+USB/DVI+VGA+USB optional
    Power InputAC 100-240V, 50/60Hz
    Power Consumption≤30W
    Power Standby≤2W
    Plug&PlayDDC1/2B
    Working LifeMore than 50,000 hours
    Operation Temperature-10°C-60°C (Support wide temperature customization)
    Storage Temperature-10°C-60°C
    Operation Humidity10%-80%
    Storage Humidity10%-90%
    Metal ShellAluminum alloy enclosure
    ColorSilver/black
    Front bezel thickness10mm bezel
    IP ratingIP65 dust-proof and water-proof for the front panel
    InstallationVESA, Embedded, Wall Mount, Desktop, open frame optional
    CertificatesCE, CCC, ISO, FCC, ROHS
    PackageEPE+Carton  (wooden crate for mass order)
