As one of the important means of transportation, the train is not only an important means of transportation in many regions but also plays an important role in the transportation of transnational trade. Then the management of the train naturally becomes one of the essential links. This article is mainly talking about train monitoring.

In train monitoring, the ATS system is used in rail transit management. The system can realize automatic train supervision and control the train operation on-line. The main functions include the edition of the operation diagram, the automatic handling of train route according to the operation diagram, the automatic adjustment of train operation interval, the manual intervention of adjusting train interval is available if necessary, and the recording of operation data, etc.

The automatic train monitoring system is a safety equipment system, including a control center system and centralized control station equipment. The central equipment includes dispatcher workstation, training simulator, control large screen, FAS and SCAD detection system, operation diagram and timetable generation printer, and other application equipment. It is connected with the platform terminal and attendant console through LAN and HUB and other Networks device connections.

Application case of Jawest train monitoring terminal

In the whole monitoring system, touch display equipment, as indispensable terminal equipment, is the main equipment for data/video display, transmission feedback, and data storage. Based on the characteristics of long-term use of trains and a large amount of data processing, the industrial all-in-one panel PC has become the first choice of many users. Take the Jawest train monitoring terminal application as an example, let's see what the users' requirements for touch display devices!

1) Application products: Jawest 11.6-inch 2nd-GEN industrial all-in-one panel PC.

2) Product advantages:

·Built in Windows operating system, optional Windows 7 / 8 / 10, Linux system.

·The thickness of the front panel PC is only 3mm, with a thin frame and easy to embed cabinet.

·This panel PC adopts the full closed and integrated design, built-in waterproof strip in the front panel, and the true flat panel reaches IP65 industrial-grade dust-proof and waterproof.

·The anti-vibration standard reaches GB2423, which conforms to the use and transportation environment of trains.

·The all-in-one panel PC has passed the quality test of controllable constant humidity, constant temperature, and pressure, which supports the stable operation of wide temperature, wide pressure operation for a long time.

·The configuration of panel PC adopts Intel Celeron J1900 quad-core 64-bit CPU, standard operating memory and hard disk storage are 2G + 32G respectively, a low-power multi-core processor is adopted, with higher integration and stability, which supports configuration upgrading to different environments.

·Multiple I/O ports for peripheral equipment connection, such as the Network monitoring camera for accepting real-time monitoring data.

·Support HDMI, VGA HD signal input, screen display resolution up to 1080P, offering clear monitoring picture.

·Support All-Network settings, including WiFi, 3G / 4G / 5G, etc., expand Cloud space and ensure the security of monitoring data.

·The embedded installation mode is adopted for simple operation. Other mounting ways such as desktop, wall-hanging, VESA 75, VESA 100 are available.

·It supports simultaneous external VGA and HDMI display to realize multi-task display and simultaneous monitoring of multiple images.

3) Project benefit

Train monitoring realizes the real-time data display and connection of front and back-end control room through the application of the industrial all-in-one panel PC and can be transmitted to the conductor and the police office through wireless mode, which is convenient for centralized monitoring and ensures the normal operation of the train.

The panel PC support to connect external Network monitoring system, high-definition display screen, meet the real-time dynamic sharing of video; support stable Network settings, real-time monitoring of cab conditions, expand Cloud storage space, and support data upload and storage. Besides, the industrial panel PC equipped with Jawest self-developed industrial motherboard, which has high-cost performance, it is a trustworthy guarantee for 7 * 24 data transmission and dynamic monitoring for the train control room.
