19.1" Industrial Touch Screen LCD Monitor Sunlight Readable Vandal-proof LED Backlight


Model: JWS191-M4

● Display size: 19.1 inch

● High-level anti-static

● High quality industrial LCD panel

● Working temperature:-10 ~ +60°C

● Industrial-grade motherboard

● 10mm Bezel Aluminum Touch Monitor

● 24/7 long time operation

● IP65 rated dustproof and water-proof for the front panel

Appearance of the color
Black
Silver
share:
  • Description
  • Parameter
  • Case
  • 19.1" Industrial Touch Screen LCD Monitor


    Model: JWS191-M4


    For the past few years, touch screen display monitors with industrial-grade quality offer applications in various industries such as smart city, transportation, education, engineering construction medical, military, manufacturing, AI and hospitality, etc. Providing multi-touch screen types, including resistive, capacitive, Infrared, or non-touchscreen for optional. With brightness levels from 300nits ~ 1500nits, the industrial TFT LCD monitor support sunlight-readable, and deliver enhanced display performance when used in outdoor application. IP65 rated dust-proof and waterproof, Full-enclosed shell for extra protection against intrusions from unwanted elements such as dirt, dust, and moisture. Moreover, the monitors are also compliant with various international certificates such as RoHS, UL, FCC, CE, ISO. Our products are highly engineered to be used in a wide variety of rugged applications where harsh environmental condition is commonplace.



    Jawest Industrial Monitor Features


    ● IP65 dust-proof and waterproof enclosure protection.

    ● Offer open frame, VESA, desktop, wall, flush & console mounting options.

    ● Advanced LCD modules with low power long service life LED backlights.

    ● water-proof strip for panel sealing, inner components are all well-protected.

    ● All assembly screws are provided in the spare parts package.

    ● High brightness levels from 300 nits to 1500 nits (high brightness belongs to customization service.)

    ● Sealess IP65 rated dust-proof and waterproof aluminum alloy enclosure.

    ● Adopt a self-developed rugged industrial-grade motherboard, support continuous operation in all-weather conditions.




    19.1" Industrial Touch Screen LCD Monitor Sunlight Readable Vandal-proof LED Backlight

    19.1" Industrial Touch Screen LCD Monitor Sunlight Readable Vandal-proof LED Backlight

    19.1" Industrial Touch Screen LCD Monitor Sunlight Readable Vandal-proof LED Backlight

    19.1" Industrial Touch Screen LCD Monitor Sunlight Readable Vandal-proof LED Backlight




  • Jawest 19.1 inch Industrial Monitor Datasheet
    Size19.1-inch
    Display
    Panel Type Industrial LCD panel A+ grade
    Aspect Ratio16:10
    Resolution1440*900
    Contrast1000:1
    Luminance250nit-1500nit
    Response time5ms
    Active Area (mm)478*269.24
    Display colors16.7M(8-bit)
    View angle89/89/89/89
    Touch ScreenCapacitive touch screen (5 wire resistive touch screen/non-touch optional)
    InterfaceHDMI+DVI+VGA+USB/DVI+VGA+USB optional
    Power InputAC 110-240V, 50/60Hz
    Power Consumption≤30W
    Power Standby≤1.5W
    Plug&PlayDDC1/2B
    Working LifeMore than 50,000 hours
    Operation Temperature-10°C-60°C (Support wide temperature customization)
    Storage Temperature-10°C-60°C
    Operation Humidity10%--80%
    Storage Humidity10%-90%
    Metal ShellAluminum alloy enclosure
    ColorSilver, black color optional
    Bezel thickness10mm bezel
    IP ratingIP65 dust-proof and water-proof for front Panel
    InstallationVESA, Embedded, Wall Mount, Desktop, open frame optional
    CertificatesCE, CCC, ISO, FCC, ROHS
    PackageEPE+Carton  (wooden crate for mass order)
