Home >> Products >> Industrial Monitor >> Embedded LCD Display
Application:
11.6 inch Industrial LCD Display With Touch Screen 1920x1080 Widescreen11.6 inch Industrial LCD Display With Touch Screen 1920x1080 Widescreen11.6 inch Industrial LCD Display With Touch Screen 1920x1080 Widescreen11.6 inch Industrial LCD Display With Touch Screen 1920x1080 Widescreen

11.6 inch Industrial LCD Display With Touch Screen 1920x1080 Widescreen


● Display size: 11.6-inch.

● High-quality industrial LCD panel.

● Working temperature: -10°C~60°C.

● Industrial grade display chip.

● 7 days*24 hours all-weather running.

● IP65 grade dust-proof and waterproof.

Appearance of the color
Black
Silver
share:
  • Description
  • Parameter
  • Case

11.6" Industrial LCD Display with 1920*1080 Widescreen


Model: JWS116-M19


Jawest provides innovative touchscreen monitors and displays to customers with popular single, gesture, and multi-touch screen applications including touchscreens and touchscreen monitors for retail point of sale, finance & banking, self-service, food service, hospitality, industrial, healthcare, manufacturing, gaming, and interactive HMI digital signage. Throughout its history, Jawest has focused on innovative technologies that make it able to carve a niche for itself in the competitive market. Through the Jawest team's rich experience and vast knowledge in this field, we are constantly moving toward the path of success.



Jawest Industrial Monitor Features


Versatile · Rugged · High Performance

The Jawest series color LCD monitor is suitably packaged in a rugged metal chassis, perfect for installation in industrial process control consoles. These rugged, high-performance, Active Matrix COLOR TFT LCD computer monitors are designed for rough industrial process control applications.



High-Quality LCD Display

Plug & play function enables this versatile industrial-grade LCD monitor to easily interface with a wide variety of video display systems. With contrast ratios exceeding 1000:1 and brightness levels from 250 cd/m2 to 1500 cd/m2, supports sunlight readable for outdoor device applications. This TFT LCD display is a good choice for most industrial display and commercial terminal needs.



Multi-Language On-Screen Display

Jawest industrial monitor offers standard features such as Plug-and-Play, multi-language on-screen display, wide viewing angle capability, IP65-rated dust-proof, and waterproof making this versatile industrial LCD monitor a good choice for much industrial automation and medical equipment.



Compatibility and Synchronization

Jawest industrial monitors are compatible with Windows, Android, and Linux OS. Support I/O port expansion.




Products Models Fast Guide


Model NameScreen SizeResolution Aspect RatioTouch TechnologyGet A Quote Now
JWS101-M1910.1"1280*80016:10Capacitive / Resistive / Non-TouchscreenInquiry
JWS104-M1910.4"1024*7684:3Capacitive / Resistive / Non-TouchscreenInquiry
JWS116-M1911.6"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS120-M1912"1024*7684:3Capacitive / Resistive / Non-TouchscreenInquiry
JWS133-M1913.3"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS150-M1915"1024*7684:3Capacitive / Resistive / Non-TouchscreenInquiry
JWS156-M1915.6"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS170-M1917"1280*10245:4Capacitive / Resistive / Non-TouchscreenInquiry
JWS173-M1917.3"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS185-M1918.5"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS190-M1919"1280*10245:4Capacitive / Resistive / Non-TouchscreenInquiry
JWS215-M1921.5"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry
JWS238-M1923.8"1920*108016:9Capacitive / Resistive / Non-TouchscreenInquiry






Industrial touch screen monitor datasheet
Size11.6 inch
Display
Panel TypeIndustrial LCD panel A, A+ grade
Aspect Ratio16:9
Resolution1920*1080
Contrast1000:1
Luminance250nit-1500nit
Response time5ms
Active Area (mm)341.5*274
Display colors16.7M(8-bit)
View angle85°/85°/85°/85° (L/R/U/D)
Touch ScreenResistive touch screen (10-point capacitive and Infrared touch for optional)
InterfaceHDMI+DVI+VGA+USB/DVI+VGA+USB optional
Power InputAC 110-240V, 50/60Hz
Power Consumption≤30W
Power Standby≤1.5W
Plug&PlayDDC1/2B
Working LifeMore than 50,000 hours
Operation Temperature-10°C~60°C
Storage Temperature-20°C~70°C
Operation Humidity10%-80%
Storage Humidity10%-90%
Metal ShellAluminum alloy enclosure
ColorSilver, black color optional
IP ratingIP65 for Front Panel
InstallationEmbedded, Wall Mount, Desktop optional
CertificatesCE, CCC, ISO, FCC, ROHS
PackageEPE+Carton  (wooden crate for mass order)
